Description
The C38 90° Corner Male Swivel has two lugs at right angles. With two C36 Female Swivels it makes an adjustable corner joint at a post, for the mid rail of a sloping handrail that turns a corner.
The same joint is available assembled as the C48 90° Corner Swivel Combination.
Specification
- Sizes: 20, 25, 32, 40 and 50, to suit tube of 26.9mm, 33.7mm, 42.4mm, 48.3mm and 60.3mm outside diameter
- Material: malleable cast iron
- Finish: hot dip galvanised as standard; powder coating to any RAL colour on request
- Assembly: grub screw and Allen key; no welding, threading or bolting
- Dimensions and weight: available on request from our technical team
Use with
C36F Female Swivel, C48 90° Corner Swivel Combination
Specify the fitting code and the size to match your tube. Order through your FastClamp distributor, or contact our technical team for a fitting list. See the full range of key clamp fittings.
